Product details
產品詳情
| ITEMS/項目 | SPECIFICATION/參數 |
| Flow-rate Range/流量范圍: | 0.016~6m3/h |
| Working Pressure Range/工作壓力: | 0~15kPa(150mbar) |
| Relative Humidity/環境濕度: | ≤93%RH |
| Operating Temperature/工作溫度: | -20°C~+55°C |
| Storage Temperature/儲存溫度: | -25°C~+60°C |
| Pressure Loss/壓損: | ≤50Pa(6m3/h) |
| Internal Leakage/內漏: | < 0.04L/h (at1.8~15kPa) |
| Durability/使用壽命: | ≈15 Years (No Fault or Damage after Continuous Working 10000 times) |
| Operating Voltage/工作電壓: | DC2.5~5.5V |
| Resistance/電阻: | 21Ω±2Ω(23°C±2°C) |
| Switching Valve Average Current /平均工作電流: | ≤80mA |
| Opening Valve Time/開閥時間: | ≤1s |
| Closing Valve Time/關閥時間: | ≤1s |
| Peak Current(Motor Start-up)/峰值電流: | ≤200mA (DC2.5V) |
| Gas Meter Application/燃?xì)獗硎褂? | G1.6~G4 Gas Meters |
| Structural Support/主要材料: | Materials are POM, Valve Seal is NBR |
| Service Fluid/工作介質: | Natural Gas/LPG |
| ATEX classification acc. To/防爆等級： | ISO EN 80079-36:2016: II 2G Ex h IIC T4 Gb |
使用說明
1.電機閥藍色線接負電，白色線接正電為：開閥。
2.嚴格按照上述“技術標準及參數”要求對閥門進行密封性測試或使用，比如工作電壓、開關閥時間、使用溫度等，否則會造成閥門無法正常工作或損壞。
3.開關閥時，施加在閥門兩端的電壓不得超過2.5V～5.5V范圍，否則會造成閥門無法正常工作或損壞。
4.此閥門的參數及結構如有變化，我司將及時通知貴司。
